For convenience, VIVI battery can be removed.
Note: The weight of battery is about 4.5-8.5 pounds. Please operate carefully.
Note: The weight of battery is about 4.5 pounds. Please operate carefully.
Applicable to models MT20 / MT20-P / FM201 / FM201-P / C26
Applicable to model T26G
Locate the quick release of seat and turn the saddle over.
Ensure the battery is turned off. Insert the key into key hole, rotate to align the
key to “OFF” and the key hole to “OFF” position.
Slide the battery upward and take it from the framework.
Make sure that the battery switch has been turned off.
Disconnect the plugged power cable connector.
Remove the battery bag along with the battery from the handlebars to complete
battery removal.
6.3.2.1
6.3.2.2
6.3.2 Disassembly of battery box
