4
STEP 3
STEP 4
Install Honey Gate (D) in Drum (A).
A
D
A
Line up holes in Lids (C) with the hinges in the crossbar of Drum (A) and secure
using M4x12 Screws (S-C) and M4 Nuts (S-D).
NOTE: Lids (C) must be installed properly and in the down position to engage the
safety switches and allow the motor to turn on. Each Lid (C) has a built in safety
latch that will cut power the moment it is opened.
Inside Drum
C
S-C
S-D
To Next Page
