Vivo BEE-V004E - Assembly Instructions; Step 1: Prepare Drum Leg Supports; Step 2: Mount Extractor Legs

3
STEP 1
Remove cap nuts and washers from the lower leg supports on Drum (A).
ASSEMBLY STEPS
STEP 2
Mount Legs (B) to Drum (A) using the previously removed hardware in the lower
holes, and M8 Plastic Knobs (S-A) with M8 Washers (S-B) in the upper holes.
A
A
B
S-A
S-B
Cap Nut
Washer
Cap Nut
Washer
