ASSEMBLY STEPS
PRE-ASSEMBLY
When fabricating custom cabinetry for your motorized TV mount, ensure there will be at least 50mm
of clearance on the sides and front of the TV along with at least 10mm of clearance on the top.
Connect cable from Motorized Li (A) to Control Unit (G).
Place AC Adapter Cover (I) over AC Adapter (H). Connect Control Unit (G) cable and Power Cable
(J) to AC Adapter (H).
STEP 1
STEP 2
G
G
I
H
J
A
