Vivotek FD8182-T User Manual

VIVOTEK
User's Manual - 231
resolutionC2P A list of <WxH> 0/7 Available resolutions of 2P mode of ceiling and
floor mount.
resolutionC1R A list of <WxH> 0/7 Available resolutions of 1R mode of ceiling and
floor mount.
resolutionC4R A list of <WxH> 0/7 Available resolutions of 4R mode of ceiling and
floor mount.
resolutionW1P A list of <WxH> 0/7 Available resolutions of 1P mode of wall mount.
resolutionW1R A list of <WxH> 0/7 Available resolutions of 1R mode of wall mount.
resolutionW4R A list of <WxH> 0/7 Available resolutions of 4R mode of wall mount.
Group: capability_videoin_c<0~(n-1)>_mode<0~(m-1)> n denotes the value of "capability_nvideoin", m
denotes the value of "capability_videoin_c<n>_nmode"
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
rotation <boolean> 0/7 Indicate this mode whether support video
rotation
effectivepixel <WxH> 0/7 The visible area of full scene in this video mode.
The unit is pixel in source.
* This value must <=
"capability_videoin_c<n>_maxsize"
* If
"effectivepixel"<"capability_videoin_c<n>_max
size", then the visible area is located at the
center of full scene.
outputsize <WxH> 0/7
T
he output size of source, equal to the captured
size by device, in this video mode. The unit is
pixel.
This value is used as a basic coordinate system
for many features, like ePTZ, privacy mask,
motion, etc.
* Source (most for image sensor) may perform
scale or binning, etc on image data, and output
data with smaller size. This parameter is
designed to represent this.
