VIVOTEK
366 - User's Manual
8.28 Camera Control
(capability_camctrl_c<0~(n-1)>_zoommodule = 1)
Note: This request requires Viewer privileges.
Method: GET/POST
Syntax: (for control API)
http://<servername>/cgi-bin/camctrl/camctrl.cgi?[channel=<value>][&camid=<value>]
[&move=<value>] – Move home, up, down, left, right
[&focus=<value>] – Focus operation
[&zoom=<value>] – Zoom in, out
[&zooming=<value>&zs=<value>] – Zoom without stopping, used for joystick
[&vx=<value>&vy=<value>&vs=<value>] – Shift without stopping, used for joystick
[&x=<value>&y=<value>&videosize=<value>&resolution=<value>&stretch=<value>] – Click on image
(Move the center of image to the coordination (x,y) based on resolution or videosize.)
[ [&speedpan=<value>][&speedtilt=<value>][&speedzoom=<value>][&speedapp=<value>][&speedlink=<val
ue>] ] – Set speeds
[&return=<return page>]
Example:
http://myserver/cgi-bin/camctrl/camctrl.cgi?channel=0&camid=1&move=right
http://myserver/cgi-bin/camctrl/camctrl.cgi?channel=0&camid=1&zoom=tele
http://myserver/cgi-bin/camctrl/camctrl.cgi?channel=0&camid=1&x=300&y=200&resolution=704x480&videosi
ze=704x480&strech=1
Example: (set the ptz preset with focus mode)
* We support this function when the version number of the PTZ control module is equal or greater than 5.0.0.20.
http://myserver/cgi-bin/camctrl/camctrl.cgi?name=xxx&focussetting=sync&cam=getsetpreset
PARAMETER VALUE DESCRIPTION
channel <0~(n-1)> Channel of video source.
camid 0,<positive integer> Camera ID.
move home Move to camera to home position.
up Move camera up.
down Move camera down.
left Move camera left.
right Move camera right.

Vivotek FD9167-H Specifications

General

Resolution	1920 x 1080
Focal Length	2.8 mm
Minimum Illumination (B/W)	0.01 Lux
Minimum Illumination (IR On)	0 Lux
Video Compression	H.265, H.264, MJPEG
Maximum Frame Rate	30 fps
Audio Compression	G.711, G.726
Audio Input	Built-in Microphone
Local Storage	MicroSD/SDHC/SDXC Card Slot
Ingress Protection	IP66
Lens Type	Fixed
Day/Night	Yes
IR Illuminators	Built-in
Network Interface	10/100 Mbps Ethernet
Protocols	IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTSP, RTP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, NTP, UpnP, SNMP
Security	User authentication, IP address filtering
Power Supply	PoE (IEEE 802.3af), 12V DC
Power Consumption	5.5W
Weight	600g
Image Sensor	1/2.8" Progressive Scan CMOS
Shutter Time	1/5 sec to 1/32, 000 sec
Minimum Illumination (Color)	0.05 lux
