VIVOTEK
User's Manual - 13
3. Plan your installation. Note the PIR sensor's coverage when selecting a installation
position.
77.3°
121°
5M
5M
4. Use the alignment sticker to drill mounting holes on the ceiling. Install the camera using
the included screws and anchors.
