VIVOTEK
User's Manual - 15
BEND
RADIUS
Cable min. bend radius 67.5mm (9x O.D.) during installation
37.5mm (5x O.D.) during operation
Cable
The cable assembly can be rigid, please note the bend radius if you need to pass
it through a narrow space. Do not fold the cable.
13. Please visit VIVOTEK’s website to Install the "Shepherd” software utility. The program
will search for VIVOTEK Video Receivers, Video Servers or Network Cameras on the
same LAN.
Double-click on the camera’s MAC address to open a web console to the camera.
LAN
PoE
Browser
Shepherd
IEEE 802.3af
To Next Page
