VIVOTEK
User's Manual - 267
© 2019 VIVOTEK INC. All Right Reserved
132
NAME VALUE SECURITY
(get/set)
DESCRIPTION
* Only available when
"capability_network_wireless" is "1".
* We support this parameter when
the version number (httpversion) is
equal or greater than 0305a.
wireless_apmode_
ssidprefix
<string> 0/7 Indicate the prefix of broadcasted
SSID when camera is in wireless AP
mode.
* Only available when
"capability_wireless_apmode_enable"
is "1".
* We support this parameter when
the version number (httpversion) is
equal or greater than 0305a.
derivative_brand <boolean> 0/7 Indicate whether to support the
upgrade function for the derivative
brand. For example, if the value is
true, the VVTK product can be
upgraded to VVXX. (TCVV<->TCXX is
excepted)
test_ac <boolean> 0/7 Indicate whether to support test ac
key.
version_onvifdaem
on
<string> 0/7 Indicate ONVIF daemon version
version_onviftestto
ol
<string> 0/7 Indicate ONVIF test tool version
media_totalspace <positive integer> 0/7 Available memory space (KB) for
media.
media_snapshot_
maxpreevent
<positive integer> 0/7 Maximum snapshot number before
event occurred.
media_snapshot_
maxpostevent
<positive integer> 0/7 Maximum snapshot number after
event occurred.
media_snapshot_
maxsize
<positive integer> 0/7 Maximum size (KB) of a snapshot.
media_videoclip_
maxsize
<positive integer> 0/7 Maximum size (KB) of a videoclip.
© 2019 VIVOTEK INC. All Right Reserved
133
NAME VALUE SECURITY
(get/set)
DESCRIPTION
media_videoclip_
maxlength
<positive integer> 0/7 Maximum length (second) of a
videoclip.
media_videoclip_
maxpreevent
<positive integer> 0/7 Maximum duration (second) after
event occurred in a videoclip.
image_iristype
<Not
recommended to
use this>
<string> 0/7 Indicate iris type.
 "piris": P-Iris
 "dciris": DC-Iris
 "-": No Iris control support
* When "capability_iris"=0, this value
must be "-".
* Note: For some box-type cameras,
this value may be varied depending on
mounted lens.
* We replace
"capability_image_iristype" with
"capability_image_c0_iristype".
* Reserved for compatibility, and
suggest don't use this since
[httpversion] > 0301a
image_focusassist
<Not
recommended to
use this>
<boolean> 0/7 Indicate whether to support focus
assist.
* We replace "capability_image_
focusassist "with
"capability_image_c0_ focusassist".
* Reserved for compatibility, and
suggest don't use this since
[httpversion] > 0301a
localstorage_mana
geable
<boolean> 0/7 Indicate whether manageable local
storage is supported.
* Only available when
"capability_supportsd" is 1 or
"capability_storage_dbenabled" is 1.
localstorage_seaml
ess
0,
<positive integer>
0/7 Indicate whether seamless recording
is supported.
One bit represents one channel.
Ex: “3” means channel 0 and channel1
