Vivotek FD9366-HV - Page 323

VIVOTEK
User's Manual - 323
© 2019 VIVOTEK INC. All Right Reserved
188
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
ftp_location string[128] 6/6 Location to upload or store the media.
ftp_passive <boolean> 6/6 Enable or disable passive mode.
0 = disable passive mode
1 = enable passive mode
email_address string[128] 6/6 Email server address.
email_sslmode <boolean> 6/6 Enable support SSL.
email_port 0~65535 6/6 Port to connect to the server.
email_username string[64] 6/6 Username to log in to the server.
email_passwd string[64] 7/6 Password of the user.
email_senderemail string[128] 6/6 Email address of the sender.
email_recipientemail string[640] 6/6 Email address of the recipient.
ns_location string[128] 6/6 Location to upload or store the media.
ns_username string[64] 6/6 Username to log in to the server.
ns_passwd string[64] 7/6 Password of the user.
ns_workgroup string[64] 6/6 Workgroup for network storage.
© 2019 VIVOTEK INC. All Right Reserved
189
7.31 Media Setting for Event Action
Group: media_i<0~(n-1)> n denotes the value of "capability_media_num"
(capability_media_num > 0)
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
Name string[40] 6/6 Identification of this entry
Type snapshot,
systemlog,
videoclip,
recordmsg
6/6 Media type to send to the server
or store on the server.
snapshot_channel 0~"capability_nvideoin"-1 6/6 Indicate the source of media
channel.
0 means the first channel.
1 means the second channel.
2 means the third channel.
3 means the fourth channel.
* We support this parameter
when the version number
(httpversion) is equal or greater
than 0311c.
snapshot_source 0~"capability_nmediastream
"-1
6/6 Indicate the source of media
stream.
0 means the first stream.
1 means the second stream and
etc.
2 means the third stream and etc.
3 means the fourth stream and
etc.
snapshot_prefix string[16] 6/6 Indicate the prefix of the
filename.
media_i0=> Snapshot1_
media_i1=> Snapshot2_
media_i2=> Snapshot3_
media_i3=> Snapshot4_
media_i4=> Snapshot5_
