VIVOTEK
326 - User's Manual
Model
FD9381-HTV:RemoteFocus
FD9381-EHTV:Remote Focus, Extreme Weather
System Information
CPU MultimediaSoC (System-on-Chip)
Flash 128MB
RAM 512MB
Camera Features
Image Sensor 1/1.8" Progressive CMOS
MaximumResolution 2560x1920 (5MP)
Lens Type Vari-Focal
Focal Length f = 4 ~ 9 mm
Aperture F1.3 ~ F2.2
Auto-iris P-iris
Field of View
45° ~ 93° (Horizontal)
34° ~ 68° (Vertical)
64° ~ 121° (Diagonal)
ShutterTime 1/5 sec. to1/32,000 sec.
WDR Technology WDR Pro
Day/Night Removable IR-
cut filter for day & night function
Minimum Illumination
0.04 Lux @ F1.3 (Color)
0.001 Lux @ F1.3 (B/W)
Pan/Tilt/Zoom
Functionalities
ePTZ:
48x digital zoom (4xon IE plug-in,12x built in)
IR Illuminators 30 meters
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
SeamlessRecording
Video
Compression H.265 & H.264 & MJPEG
MaximumFrame Rate
H.265 & H.264:
30 fps @ 2560x1920
60 fps @ 1920x1080
MJPEG:
12 fps @ 2560x1920
30 fps @ 1920x1080
MaximumStreams 4 simultaneousstreams
S/N Ratio 57 dB
Dyna
mic Range 100 dB
Video Streaming
Adjustable resolution, quality and bitrate
Smart Stream II
Image Settings
Time stamp, textoverlay, flip & mirror
Configurable brightness, contrast, saturation, sharpness, white
balance, exposure control, gain, backlight compensation,
privacy masks
Scheduled profilesettings, 3DNR, videorotation,defog, DIS
Audio
AudioCapability Two-Way Audio (full duplex)
Compression G711, G726
Interface
External microphone input
Audiooutput
Network
Users Live viewing forup to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS,SNMP,
802.1X, UDP, ICMP, ARP, SSL, TLS
Interface
10 Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to usestandard CAT5e & CAT6 cables
which are compliant with the 3P/ETL standard.
ONVIF Supported, specifications available at www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
VCA* Line cro
ssing detection, field detection,loitering detection
Technical Specifications
Compatible Accessories
Alarm and Event
Alarm Triggers
Motiondetection, manual trigger,digital input,
periodicaltrigger, system boot, recording notification, camera
tamperingdetection, audio detection
Alarm Events
Event notification using digital output, HTTP, SMTP, FTP and NAS
server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD card
General
Smart Focus System RemoteFocus
Connectors
RJ-45 cable connector for Network/PoE connection
Audioinput
Audiooutput
DC 12V power input
Digital input*1
Digital output*1
LED Indicator System powerand status indicator
Power Input
DC12V
FD9381-HTV:IEEE 802.3af/at PoE Class0
FD9381-EHTV:IEEE 802.3at PoE Class 4
Power Consumption
FD9381-HTV:Max. 12.8 W
FD9381-EHTV:Max. 25.5 W (Heater on)
Dimensions Ø 155 x 103 mm
Weight
FD9381-HTV:927 g
FD9381-EHTV:928 g
Casing
Weather-proof IP66-rated housing
Vandal-proof IK10-rated metal housing
Safety Certifications CE, LVD, FCC Class A, VCCI, C-Tick, UL
Operating Temperature
FD9381-HT
V:
Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
FD9381-EHTV:
Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F)
Humidity 90%
Warranty 36 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~10 (streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's m
anual,quickinstallation guide, Installation Wizard 2,
VAST
Others
Quick installation guide, screw pack,alignment sticker, desiccant
bag, water-proof connectors, conduit connector
Dimensions
Ø155 mm
103 mm
Mounting Kits PoE Kits
AM-51C (v01)
Adapter Ring
AM-525 (v01)
Mounting Adapter
AM-713 (v01)
Conduit Box
AP-FXC-0251
PoE Extenderwith
Conduit Box
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
VIVOTEK INC.
2050 Ringwood Avenue,
San Jose, CA 95131
T: 408-773-8686 F: 408-773-8298
E: salesusa@vivotek.com
VIVOTEK USA
Ver. 3
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
Randstad 22-133, 1316BW Almere,
The Netherlands
T: +31(0)36-5298-434
E: saleseurope@vivotek.com
VIVOTEK Europe
602, Best sky Tower, Plot No. F-5,
Netaji Subhash Place, Pitam Pura, Delhi-110 034
T: +91-11-45137465
E: salesindia@vivotek.com
VIVOTEK India
* Available per project request.
