Vivotek FD9381-EHTV - Hardware Installation

VIVOTEK
6 - User's Manual
Ethernet 10/100 RJ45 Plug
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
Hardware Installation
0002D10766AD
XXXXXX
1
1. Jot down the camera's MAC address for later reference.
IMPORTANT:
The FD9371-EHTV and FD9381-EHTV come with an embedded heater and require
an 802.3at PoE switch.
Model Consumption & PoE PSE
FD9371-HTV DC 12V - 9.6W / PoE - 12W (IEEE 802.3af)
FD9381-HTV DC 12V - 11.6W / PoE -12.8W (IEEE 802.3af)
FD9371-EHTV DC 12V - 21W / PoE - 24.7W (IEEE 802.3at)
FD9381-EHTV DC 12V - 23W / PoE - 25.5W (IEEE 802.3at)
