Image Capture with Greater Data Efficiency

Product Features

• Flexible Display Mode

The overview image captured by the FE8171V can be tailored in various ways according to specific applications.

The FE8171V offers multiple types of display layouts in the web browser interface, including 1O, 1O3R, 1O8R, 1P, 2P, 1P2R, 1P3R, 1R, 4R and 4R PRO. The

following diagrams show several of the display modes:

1O3R – provide details

of three 720p cameras

1O 1P

1O8R – provide details

of eight VGA cameras

Comprehensive Overview without Blind Spots

With a wide-angle field of view, the FE8171V is able to capture 180° panoramic or 360° surround views without blind spots, effectively reducing the need for

other cameras as well as physical maintenance.

Enhanced Security

Reliability in Demanding Environments

• 180° Panoramic View

The FE8171V can provide an overview of the region from wall to wall.

• 360° Surround View

When mounted on the ceiling, the FE8171V can monitor all four corners of a room. Any moving object in the room will be captured at all times. The viewer

would be able to keep a track of suspicious objects without missing critical information.

• ePTZ

The FE8171V provides electronic pan/tilt/zoom functions, allowing users to

move to a target region in the viewing window without a mechanical movement.

In a “panoramic view” and a “regional view”, users can utilize the ultra-smooth

ePTZ function to easily focus on a region of interest (ROI) using the mouse

wheel.

Compared to the conventional mechanical PTZ, the ePTZ feature offers

zero-wait operation through client-side control. In addition, with a high-end

dewarping algorithm (plug-in), the ePTZ on the FE8171V responds swiftly

and seamlessly to user’s control.

• Clear Images 24/7

The FE8171V deliver day & night functionality with a built-in removable IR-cut

filter. By day, the IR-cut filter screens out infrared light to reduce color distortion.

At night, the filter is removed to accept infrared light for higher lighting efficiency.

• Vandal-proof IK10-rated Housing

Equipped with a protective housing, the FE8171V is protected from vandalism, making it

suitable for high-risk environments. The metal base and polycarbonate cover enable the

FE8171V to withstand high impacts, thereby ensuring functional operation at all times.

• EN50155 Compliance

With resistance to an extended temperature range of -25° C to 50° C, the FE8171V is

compliant with the EN50155 standard for electronic equipments operating in railway

vehicles. It also meets the EN50155's shock and vibration requirements to provide

high reliability and rugged performance during movement.

• IP66-rated Housing

The weather-proof IP66-rated housing provides protection from dust and moisture,

allowing the FE8171V to operate in the outdoor setting under a multitude of weather

conditions.

Dewarp

Optical distortion is unavoidable for ultra wide-angle and fisheye lenses. The hemispherical images captured from the fisheye camera are convex, especially the image borders; however,

software allows the image to be dewarped and remapped into conventional rectilinear projection using an integrated plug-in for specific viewing and analysis.

In 4R PRO mode, the four viewing windows will rotate synchronously while clicking or dragging

one of the windows.

The “1O” refers to the original image without processing. For legal purposes, keeping the raw data can be very important and necessary for forensic experts to

conduct analysis during the examination process.

3.1MP • 360° Surround View • Vandal-proof

FE8171V

Fisheye Network Camera

• 3.1-Megapixel CMOS Sensor

• 1.27 mm Fisheye Lens for 180° Panoramic View and 360° Surround View

• Removable IR-cut Filter for Day and Night Function

• EN50155 Compliance for Professional Mobile Surveillance

• Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)

• WDR Enhancement for Unparalleled Visibility in Extremely Bright or Dark Environments

• Vandal-proof IK10-rated and Weather-proof IP66-rated Housing

• ePTZ for Data Efficiency
