VIVOTEK
User's Manual - 201
weekday 0~127 127 6/6 Indicate which weekday is
scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on
Friday and Sunday, set weekday as
66.
begintime hh:mm 00:00 6/6 Start time of the weekly schedule.
endtime hh:mm 24:00 6/6 End time of the weekly schedule.
(00:00~24:00 indicates schedule
always on)
prefix string[16] <blank> 6/6 Indicate the prefix of the filename.
cyclesize 200~ 100 6/6 The maximum size for cycle
recording in Kbytes when choosing
to limit recording size.
(not used in FE8174, FE8181)
reserveamount 0~ 100 6/6 The reserved amount in Mbytes
when choosing cyclic recording
mechanism.
dest cf,
0~4
cf 6/6 The destination to store the
recorded data.
“cf” means local storage (CF or SD
card).
“0” means the index of the network
storage.
cffolder string[128] NULL 6/6 Folder name.
filesize 102400~2048000 102400 6/6 Unit: Mega bytes.
When this condition is reached,
recording file is truncated.
duration 0~3600 60 6/6 Uuit: Minute
When this condition is reached,
recording file is truncated.
