10 - User's Manual
First, open the dome cover by pressing the release button. You may squeeze the opposite edge
of the dome cover if the dome cover does not come off easily. Then, follow the steps below to in-
stall the camera to either a ceiling or a wall.
Hardware Installation - FE9181-H
Opening Dome Cover
Release
button
If you plan to route cables from the side of camera,
remove the rubber slide cover from the dome cover.
Slide cover
Connect the supplied power & IO cables if your
switch does not support PoE. Connect the white
header connectors to J12 and J7 on the camera.
Connecting Ethernet Cable
& the Power and IO Cable
J12
J7
Power and IO
cables
