VIVOTEK
8 - User's Manual
Physical Description - FE9381-EHV (Outdoor)
Inner View
Header (J7)
Spring Contacts (A)
Lens
Contacts for Internal Microphone (B
)
Header (J12)
Ethernet 10/100 RJ45 Socket
i
Align (B) to (A) when attaching the
dome cover
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
