Vivotek FE9380-HV - Media > Video; Mode; Stream Settings

VIVOTEK
User's Manual - 79
Media > Video
Stream settings
Please follow the steps below to set up those settings for an individual stream:
1. Select a stream to congure its viewing region.
2. Choose a proper
Frame Size
from the drop-down list according to the size of monitored device.
3. Select the Maximum frame rate.
■ The parameters of a xed-focal lens' multiple streams:
Region of Interest
Stream 1 1920 X 1920 ~ 256 x 256
Stream 2 1536 X 1536 (default) ~ 256 x 256
Stream 3 512 X 512 (default) ~ 256 x 256
Stream 4 1920 X 1920 ~ 256 x 256
To begin the conguration, rst select a video channel.
To change the frame size, frame rate, and other related settings, click on video settings for a video
stream to its individual conguration panel.
Mode
When the WDR Pro feature is enabled, the maximum frame rate will be reduced to 24fps.
