Model
IB8382-T: Vari-focal, P-iris, Remote Focus
IB8382-ET: Vari-focal, P-iris, Remote Focus, Extreme
Weather
IB8382-F3: Fixed-focal
IB8382-EF3: Fixed-focal, Extreme Weather
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 1Gb
RAM 4Gb
Camera Features
Image Sensor 1/3.2" Progressive CMOS
Maximum Resolution 2560x1920 (5MP)
Lens Type
Vari-focal, Remote Focus (IB8382-T/-ET)
Fixed-focal (IB8382-F3/-EF3)
Focal Length
IB8382-T/IB8382-ET: f = 3 ~ 9 mm
IB8382-F3/IB8382-EF3: f = 3.6 mm
Aperture
IB8382-T/IB8382-ET: F1.2 ~ F2.3
IB8382-F3/IB8382-EF3: F2.1
Auto-iris P-iris (IB8382-T/IB8382-ET)
Field of View
IB8382-T/IB8382-ET:
35° ~ 78° (Horizontal)
27° ~ 54° (Vertical)
44° ~ 100° (Diagonal)
IB8382-F3/IB8382-EF3:
92° (Horizontal)
76° (Vertical)
105° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Enhanced
Day/Night Removable IR-cut filter for day & night function
Minimum Illumination
IB8382-T/IB8382-ET:
0.04 Lux @ F1.2 (Color)
0.001 Lux @ F1.2 (B/W)
IB8382-F3/IB8382-EF3:
0.089 Lux @ F2.1 (Color)
0.001 Lux @ F2.1 (B/W)
Pan/tilt/zoom Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built in)
IR Illuminators
Built-in IR illuminators, effective up to 30 meters
with Smart IR
IR LED*8
On-board Storage
Slot type: SD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.264 & MJPEG
Maximum Frame Rate
15 fps @ 2560x1920
15 fps @ 2408x1536
30 fps @ 1920x1080
In both compression modes
Maximum Streams 4 simultaneous streams
S/N Ratio Above 65 dB
Dynamic Range 70 dB
Video Streaming Adjustable resolution, quality and bitrate; Smart Stream
Image Settings
Adjustable image size, quality and bit rate, time stamp,
text overlay, flip & mirror, configurable brightness,
contrast, saturation, sharpness, white balance, exposure
control, gain, backlight compensation, privacy masks,
scheduled profile settings, 3D noise reduction, video
rotation, defog
Audio
Audio Capability Two-way Audio (full duplex)
Compression G.711, G.726
Interface
External microphone input
Audio output
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP,
IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS,
QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
Interface
10Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard Cat. 5e & Cat.
6 cables which are compliant with the 3P/ETL standard.
ONVIF Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
VCA*
Line crossing detection, field detection, loitering
detection
Technical Specifications
Compatible Accessories
Alarm and Event
Alarm Triggers
Video motion detection, manual trigger, digital input,
periodical trigger, system boot, recording notification,
camera tampering detection, audio detection
Alarm Events
Event notification using digital output, HTTP, SMTP, FTP
and NAS server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD card
General
Smart Focus System IB8382-T/IB8382-ET: Remote Focus
Connectors
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
DC 12V power input
Digital input*1
Digital output*1
LED Indicator System power and status indicator
Power Input
DC 12V
IEEE 802.3at PoE
Power Consumption
IB 8 382-T:
Max. 8 W (DC12V)
Max. 9.5 W (PoE)
IB8382-ET/-EF3:
Max. 21/8 W (DC12V-Heater on/off)
Max. 25/9.5 W (PoE-Heater on/off)
IB8382-F3:
Max. 7.5 W (DC12V)
Max. 9 W (PoE)
Dimensions Ø 88 x 293 mm
Weight Net: 1264 g
Casing
Weather-proof IP66-rated housing
Vandal-proof IK10-rated metal housing (Casing only)
Safety Certifications
IB8382-T/-ET:
CE, LVD, FCC Class A, VCCI, C-Tick, UL
IB8382-F3/-EF3:
CE, LVD, FCC Class A, VCCI, C-Tick
Operating Temperature
IB8382-T/-F3:
Starting Temperature: -10°C ~ 50°C (14°F~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F~ 122°F)
IB8382-ET/-EF3:
Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F)
Warranty
IB8382-T/-ET: 36 months
IB8382-F3/-EF3: 24 months
System Requirements
Operating System Microsoft Windows 7/8/Vista/XP/2000
Web Browser
Mozilla Firefox 7~10 (Streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's manual, quick installation guide, Installation
Wizard 2
Others
Quick installation guide, warranty card, sun shield, wall
mount bracket, waterproof RJ45 Ethernet enclosure,
alignment sticker / desiccant bag, waterproof connector,
screw
Dimensions
88 mm
80 mm
293 mm
Mounting Kits
AM-714
Junction Box
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
VIVOTEK INC.
2050 Ringwood Avenue,
San Jose, CA 95131
T: 408-773-8686 F: 408-773-8298
E: salesusa@vivotek.com
VIVOTEK USA
Ver. 10
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
Randstad 22-133, 1316BW Almere,
The Netherlands
T: +31(0)36-5298- 434
E: saleseurope@vivotek.com
VIVOTEK Europe
602, Best sky Tower, Plot No. F-5,
Netaji Subhash Place, Pitam Pura, Delhi-110 034
T: +91-11-45137465
E: salesindia@vivotek.com
VIVOTEK India
* Available per project request
