lowlightcondition 0, 1 6/6 0 => Do action at all times
1 => Do action in low-light conditions
action_do_i<0~(ndo-1)
>_enable
0, 1 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 6/6 Duration of the digital output trigger in seconds.
action_cf_enable 0. 1 6/6 Enable media write on CF.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4 6/6 Index of the attached media.
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
action_server_i<0~4>_e
nable
0, 1 6/6 Enable or disable this server action.
The default value is 0.
action_server_i<0~4>_
media
NULL, 0~4 6/6 Index of the attached media.
action_server_i<0~4>_
datefolder
<boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
action_goto_enable <Boolean> 6/6 Enable/disable ptz goto preset on event triggered.
action_goto_name string[40] 6/6 Preset name that ptz goto on event triggered.
Group: server_i<0~4>
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
name string[40] 6/6 Identification of this entry
type email,
ftp,
http,
ns
6/6 Indicate the server type:
“email” = email server
“ftp” = FTP server
“http” = HTTP server
“ns” = network storage
http_url string[128] 6/6 URL of the HTTP server to upload.
http_username string[64] 6/6 Username to log in to the server.
http_passwd string[64] 6/6 Password of the user.
ftp_address string[128] 6/6 FTP server address.
ftp_username string[64] 6/6 Username to log in to the server.
ftp_passwd string[64] 6/6 Password of the user.
ftp_port 0~65535 6/6 Port to connect to the server.
ftp_location string[128] 6/6 Location to upload or store the media.
