EN-3
English
Physical Description
2
Connectors
Ethernet 10/100 RJ45 Plug
Power Cord Socket (Black)
General I/O Terminal Block
Front Panel
IR LED
Lens
Reset Button
Status LED
Light Sensor
Back Panel
