VIVOTEK
174 - User's Manual
1280x1024
videoin_c0_mode0_
effectivepixel
<WxH> IP8365:
1920x1080
IP8355:
1280x1024
0/7 The visible area of full scene in
this video mode.
The unit is pixel in source.
* This value must <=
"capability_videoin_c<n>_max
size"
* If "effectivepixel" <
"capability_videoin_c<n>_max
size", then the visible area is
located at the center of full
scene.
videoin_c0_mode0_
outputsize
<WxH> IP8365:
1920x1080
IP8355:
1280x1024
0/7 The output size of source, equal
to the captured size by device,
in this video mode. The unit is
pixel.
This value is used as a basic
coordinate system for many
features, like ePTZ, privacy
mask, motion, etc.
* Source (most for image
sensor) may perform scale or
binning, etc on image data, and
output data with smaller size.
This parameter is designed to
represent this.
videoin_c0_mode0_
binning
binning 0 0/7 Indicate binning is used or not in
this video mode.
0: No binning
1: 2x2 binning
3: 3x3 binning
videoin_c0_mode0_
nresolution
<positive integer> IP8365:
7
IP8355:
8
0/7 Available resolutions list.
videoin_c0_mode0_r
esolution
<a list of available
resolution separated
IP8365:
176x144,
0/7 Available resolutions list.
