Vivotek IP8362 - Page 153

VIVOTEK
User's Manual - 153
weekday 0~127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and Sunday, set
weekday as 66.
begintime hh:mm 6/6 Begin time of the weekly schedule.
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
lowlightcondition
<product dependent>
0, 1 6/6 Switch on white light LED in low light condition
0 => Do action at all times
1 => Do action in low-light conditions
action_do_i<0~(ndo-1
)>_enable
0, 1 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1
)>_duration
1~999 6/6 Duration of the digital output trigger in seconds.
action_goto_enable
<product dependent>
<Boolean> 6/6 Enable/disable ptz goto preset position on event triggered.
action_goto_name
<product dependent>
string[40] 6/6 Specify the preset name that ptz goto on event triggered.
action_cf_enable <Boolean> 6/6 Enable or disable sending media to SD card.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4 6/6 Index of the attached media.
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
action_cf_backup <Boolean> 6/6 Enable or disable the function that send media to SD card for
backup if network is disconnected.
action_server_i<0~4>
_enable
0, 1 6/6 Enable or disable this server action.
action_server_i<0~4>
_media
NULL, 0~4 6/6 Index of the attached media.
action_server_i<0~4>
_datefolder
<boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
