Vivotek IP8362 - Page 76

VIVOTEK
76 - User's Manual
NOTE
► All the items in the “Region of Interest” should not be greater than the “Output Frame Size“ (current
maximum resolution).
■ The parameters of the multiple streams:
When completed with the settings in the Viewing Window, click
Save
to enable the settings and click
Close
to exit the window. The selected
Output Frame Size
will immediately be applied to the
Frame
size
of each video stream. Then you can go back to the home page to test the e-PTZ function. For more
information about the e-PTZ function, please refer to page 85.
Region of Interest Output frame size
Stream 1 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 2 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 3 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 4 1920 X 1080 (Fixed) 1920 X 1080 ~ 176 x 144 (Selectable)
Output Frame Size
(Size of the Live View Window)
Region of Interest
(Viewing Region)
