VIVOTEK
User's Manual - 147
quality.
100 is percentage mode.
s<0~(m-1)>_mjpeg
_qvalue
2~97 29 4/4 Manual video quality level input.
(s<0~(m-1)>_mjpeg_quant =
99)
s<0~(m-1)>_mjpeg
_qpercent
1~100 49 4/4 Manual video quality level input.
(s<0~(m-1)>_mjpeg_quant =
100)
s<0~(m-1)>_mjpeg
_bitrate
1000~20000000 16000000 4/4 Set bit rate in bps when choosing
cbr in “ratecontrolmode”.
s<0~(m-1)>_mjpeg
_maxvbrbitrate
1000~40000000 40000000 4/4 Set bit rate in bps when choosing
vbr in “ratecontrolmode”.
s<0~(m-1)>_mjpeg
_maxframe
1~50,
51~60 (only for
NTSC or 60Hz
CMOS)
13 1/4 Set maximum frame rate in fps
(for JPEG).
5M : 1~13fps
3M : 1~20fps
2M : 1~30fps
1080P : 1~30fps
720P : 1~60fps
(for NTSC or 60Hz CMOS)
wdrc_mode 0~3 0 4/4 WDR enhanced.
0: off
1: auto
2: always on
3: keep current value
wdrc_strength 0~2 1 4/4 WDR enhanced.
0: low
1: medium
2: high
