VIVOTEK
230 - User's Manual
<product
dependent>
-: Not supported.
motion_wintype rectangle, polygon 0/7 The supported motion window type.
polygon: The window is a 2D polygon shape.
rectangle: The window is a 2D rectangle
shape.
motion_windomain qvga, px, std, - 0/7 The domain to set an motion window.
qvga: a 320x240 range to represent the whole
image.
px: Locate a window in the image with pixels.
std: A normalized 0~9999 range.
-: Not supported.
smartstream_support <boolean> 0/7 Indicate whether smart stream is supported.
smartstream_version <integer> 0/7 Number of smart stream version
smartstream_nstream <positive integer> 0/7 Number of stream that support smart stream.
* Only available when
"capability_smartstream_support" is 1
smartstream_windomain qvga, px, std, - 0/7 The domain to set an focus window.
qvga: a 320x240 range to represent the whole
image.
px: Locate a window in the image with pixels.
std: A normalized 0~9999 range.
-: Not supported.
* Only available when
"capability_smartstream_support" is 1
smartstream_mode_autot
racking
<boolean> 0/7 Indicate whether autotracking smart stream is
supported.
* Only available when
"capability_smartstream_support" is 1
smartstream_mode_man
ual
<boolean> 0/7 Indicate whether manual smart stream is
supported.
* Only available when
"capability_smartstream_support" is 1
smartstream_mode_hybri
d
<boolean> 0/7 Indicate whether hybrid(autotracking+
manual) smart stream is supported.
* Only available when
"capability_smartstream_support" is 1
smartstream_nwindow_a
utotracking
<positive integer> 0/7 Maximum number of tracking window of
autotracking.
