Symbols and Statements in this Document
i
INFORMATION: provides important messages or advices that might help prevent
inconvenient or problem situations.
NOTE: Notices provide guidance or advices that are related to the functional integrity of
the machine.
Tips: Tips are useful information that helps enhance or facilitae an installation, function,
or process.
WARNING: or IMPORTANT:: These statements indicate situations that can be
dangerous or hazardous to the machine or you.
Electrical Hazard: This statement appears when high voltage electrical hazards might
occur to an operator.
Physical Description
Inner View
Outer View
Lens
MicroSD/SDHC/SDXC
Card slot
Reset button
Status LED
Lens
Twist adjustment ring
Tilt retention screw
Main body
on base plate
IR LEDs
Mounting hole
Tilt retention screw
IR LEDs
Contacts for heater pad
T10 top cover retention screw
Front window
retention bracket
Top cover
