VIVOTEK
User's Manual - 351
Technical Specifications
Models MD8564-EH
Camera Features
Image Sensor 1/2.8 progressive CMOS
Maximum Resolution 1920x1080 (2M P)
Lens Type Fixed-focal
Focal Length 6mm
ICR Yes
IR Illuminators 30 meters
Field of View 56° (H), 30° (V)
Shutter Time 1/5" sec. to 1/32,000 sec.
WDR Technology WDR Pro
Defog Yes
De-icing Yes
Day/Night Yes
Minimum Illumination
0.18 L ux
0.001 lux (B/W)
0 lux with IR illumination on
Tilt Range 0~30°
Rotation Range ±90 degree
Pan/tilt/zoom
Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in,12x
built in)
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264, MJPEG
Maximum Frame Rate 30 fps @ 1920X1080
Maximum Streams 4 simultaneous streams
S/N Ratio
47 dB
With adjustable 2DNR & 3DNR
3DNR Yes
Dynamic Range 100dB
Video Streaming
Adjustable resolution, quality and
constant bit rate control
Smart Stream II
Image Settings
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast,
saturation, sharpness, white balance,
exposure control, gain, backlight
compensation, privacy masks
Scheduled profile settings, 3DNR, video
rotation
Audio
Audio Capability Two-way audio
Compression G.711, G.726
Interface
External microphone
External line out
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, F TP, DHCP,
NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X, SSL/TLS, ARP
Interface
10Base-T/100 BaseTX Ethernet (M12,
Female, 4pin D-coded)
ONVIF Latest version
Intelligent Video
Video Motion Detection Five-window video motion detection
Seamless recording Yes
Smart stream II Yes
Privacy mask
Five privacy mask; full frame rate with 5
privacy masks on
Tampering detection Full frame rate with tampering detection
VADP Yes
MD8564-EH
Mobile Dome Network Camera
Technical Specifications
Alarm and Event
Alarm Triggers
Motion detection, manual trigger,
periodical trigger, system boot, recording
notification, camera tampering detection
Alarm Events
Event notification using HTTP, SMTP, FTP
and NAS server, SD Card
File upload via HTTP, SMTP, FTP, NAS
server and SD card
General
Connectors
M12 for Network/PoE connection
M12 for DC power for heater
Digital input*1
Digital output*1
Audio input*1
Audio Line out*1
LED Indicator System power and status indicator
Power Input
IEEE 802.3at PoE Class 4
DC 24V (heater)
Casing
Weather-proof IP68-rated housing
Vandal-proof IK10-rated metal housing
NEMA 4X
Safety Certifications
CE, LVD, FCC Class B, VCCI, C-Tick, IP68,
IK10, NEMA 4X, EN45545, EN50155 TX,
EN50121-3-2, EN61373, EN50121-4
Operating Temperature
Starting Temperature:
-40°C ~ 70°C (-40°F~ 158°F)
Working Temperature:
-40°C ~ 70°C (-40°F~ 158°F
Warranty 36 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~43 (Streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's manual, quick installation guide,
Installation Wizard 2, VAST
Others
Quick installation guide, screwdriver,
alignment sticker, software CD
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 3-2 (Project)
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. | T: +886-2-82455282 | F: +886-2-82455532 | E: sales@vivotek.com | W: www.vivotek.com
