VIVOTEK
406 - User's Manual
Technical Specications
Model MD9560-DH
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9" Progressive CMOS
Max. Resolution 1920x1080 (2MP)
Lens Type Fixed-focal
Focal Length f = 2.8 mm
Aperture F1.8
Iris type Fixed-iris
Field of View
108° (Horizontal)
60° (Vertical)
124° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night Yes
Removable IR-cut lter Yes
IR Illuminators Built-in IR illuminators, effective up to 20 meters with Smart IR, IR LED*2
Minimum Illumination
0.13 Lux @ F1.8 (Color)
0.01 Lux @ F1.8 (B/W)
0 Lux with IR illumination on
Pan Range ±30°
Tilt Range 90°
Rotation Range ±180°
Pan/Tilt/Zoom Functionalities ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265, H264, MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
Maximum Streams 3 simultaneous streams
S/N Ratio 60 dB
Dynamic Range 120 dB
Video Streaming Adjustable resolution, quality and bitrate, Smart Stream III
Image Settings
Adjustable image size, quality and bit rate; Time stamp, text overlay, ip & mirror; Congurable
brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight
compensation, privacy masks; Scheduled prole settings, 3DNR, video rotation, defog
