Technical Specications
Model MD9560-DH
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9" Progressive CMOS
Max. Resolution 1920x1080 (2MP)
Lens Type Fixed-focal
Focal Length f = 2.8 mm
Aperture F1.8
Iris type Fixed-iris
Field of View
108° (Horizontal)
60° (Vertical)
124° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night Yes
Removable IR-cut lter Yes
IR Illuminators Built-in IR illuminators, effective up to 20 meters with Smart IR, IR LED*2
Minimum Illumination
0.13 Lux @ F1.8 (Color)
0.01 Lux @ F1.8 (B/W)
0 Lux with IR illumination on
Pan Range ±30°
Tilt Range 90°
Rotation Range ±180°
Pan/Tilt/Zoom Functionalities ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265, H264, MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
Maximum Streams 3 simultaneous streams
S/N Ratio 60 dB
Dynamic Range 120 dB
Video Streaming Adjustable resolution, quality and bitrate, Smart Stream III
Image Settings
Adjustable image size, quality and bit rate; Time stamp, text overlay, ip & mirror; Congurable
brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight
compensation, privacy masks; Scheduled prole settings, 3DNR, video rotation, defog
Technical Specications
Audio
Audio Capability One-way Audio
Compression G.711, G.726
Interface
Built-in microphone
External line input
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols
802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4,
IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
Interface 10Base-T/100 BaseTX Ethernet (M12, Female, 4pin D-coded)
ONVIF Supported, specication available at www.onvif.org
Solution Integration
Video Motion Detection Five-window video motion detection
VADP Package Trend Micro IoT Security, Stratocast
Alarm and Event
Alarm Triggers
Motion detection, manual trigger, digital input, periodical trigger, system boot, recording
notication, camera tampering detection, audio detection, SD card life expectancy, cybersecurity
events (brute force attack event, cyberattack event, quarantine event)
Alarm Events
Event notication via digital output, email, HTTP, FTP, NAS server, SD card
File upload via email, HTTP, FTP, NAS server, SD card
General
Connectors
M12 for Network connection*1
DC power input*1
Audio input*1
Digital input*1 (30V, 1A)
Digital output*1 (12V, 50mA)
LED Indicator System power and status indicator
Power Input DC 7.5 ~ 48V
Power Consumption
Max. 5.5 W (IR on)
Max. 3.3 W (IR off)
Dimensions 98 x 54 x 110.8 mm
Weight 400 g
Casing IP66, IP67, IK10, NEMA 4X
Safety Certications
CE, LVD, FCC Class B, VCCI, C-Tick, UL, NEMA 4X, EN50155 2017 OT1/ST1, IEC60571,
EN61373, EN50121-3-2, EN50121-4, EN50132-7, EN45545 HL1, IEC62236-3-2, IEC62236-3-2,
EN60068-2-1, EN60068-2-2, ECE R118, E-Mark
Operating Temperature
Starting Temperature:
-25°C ~ 55°C (-13°F~ 131°F)
Working Temperature:
-25°C ~ 60°C (-13°F~ 140°F) (IR off)
-25°C ~ 55°C (-13°F~ 131°F) (IR on)
Maximum (intermittent): 70 °C (158 °F)
Humidity 98%
