Vivotek PZ7111 - Network Deployment; General Connection Setup

EN - 6
General Connection (without PoE)
1. If you have external devices such as sensors and alarms, make connections from gen-
eral I/O terminal block.
2. Connect the camera to a switch via a Ethernet cable.
3. Connect the supplied power cable from the camera to a power outlet.
ee
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
AV
2
3
Ethernet switch
Network Deployment
4
1: Power
2: Digital output
3: Digital input
4: Ground
