VIVOTEK
User Guide - 9
The following applies when stitching multiple SC8131 cameras:
1. The
Stitching
conguration takes place on the
Master
camera. 1 Master camera with
up to 6 Slave cameras can form a stitiching conguration.
2. All Master and Slave cameras in a Stitching conguration should be running the same
rmware.
3. The physical positions of cameras should be consistent with the stitching order. It is
recommended you keep a note of all cameras' positions and IP addresses. Static IP
addresses are prefereed.
4. Select a camera on the edge of the line as the Master camera.
5. Recruit the Slave cameras via a web console to the Master camera.
6. When software conguration is done, it is best to have human trafc in and through the
coverage areas of these cameras. If there are no trafc when you congure the Stitching
conguration, you should have someone walking in the overlapped areas.
The peer cameras then automatically calculate the coordinations of the same moving
objects that appear in the overlapped FOVs between them. The walking should persist
for at least 2 minutes.
407
700
407
293
Overlapped Area
Stitching Considerations
To Next Page
