VIVOTEK
4 - User's Manual
Overview
VIVOTEK's SD9161-H is a high-performance H.265 speed dome network camera, offering
1080p Full HD resolution and consistently superb image quality. Adopting the power of a 10x
optical zoom lens and the maneuverability of a sophisticated pan/tilt mechanism, the SD9161-H
is able to capture ne detail at top-notch quality and is especially suitable for wide-open indoor
spaces, such as airports and lobbies, where the highest levels of reliability and precision are
required.
Featuring the Wide Dynamic Range Technology, WDR Pro, the SD9161-H provides improved
visibility in both extremely dark and light environments. Additionally, this unique camera also
supports VIVOTEK's sophisticated Smart Stream II, enabling the optimization of quality for
desired regions and thus delivering the maximum possible efficiency of bandwidth usage.
Combining H.265 compression technology and VIVOTEK's Smart Stream II technology, users
can enjoy bandwidth savings of up to 80%* compared to traditional H.264 systems.
Incorporating a number of advanced features standard for VIVOTEK cameras, including EIS,
tamper detection, MicroSD/SDHC/SDXC card slot, and VIVOTEK's 32-channel recording
software, the SD9161-H is the ideal solution for your indoor surveillance needs.
* Depending on scene being monitored
Revision History
■ Rev. 1.0: Initial release
■ Rev. 1.1: Added the description for the Focus window function. Added the pinout information for the I/O
combo cable.
■ Rev. 1.2: Corrected DI/DO pin related description and the available TCP Port options. Replace the
wall-mount bracket with the AM-21C.
■ Rev. 1.3: Updated password policy, SD card capacity, video profiles, use of RTSP players,
authentication, system time time zone, logs, RTSP streaming, and URL command update.
IMPORTANT:
Below are the requirements for powering the the speed dome:
Feature Power Consumption
802.3at PoE 15W
AC/DC 24V 15W
NOTE:
If powered by a power adapter, the adapter should be properly grounded.
