Vivotek VC8101 - Page 13

VIVOTEK
User's Manual - 13
12
Secure the lens unit to wall by driving screws through the mount bracket.
13
55mm
Find an appropriate location for the main body. Drive two screws 55mm apart into the wall, and
then you can hang the main body onto a surface.
