Vivotek VC8101 - Hardware Installation

VIVOTEK
User's Manual - 7
5m
3
Hardware Installation
4
- OR -
DC8~36V PoE 802.3af
M
icro
SD
The camera can be installed through a wall. Make sure the lens unit cable can be properly
routed.
Connect other devices, such as detectors, alarm, speaker or microphone. The camera can
be powered by a DC output or a PoE switch. If local storage is preferred, install a Class 6
MicroSD card.
