VIVOTEK
8 - User's Manual
Drill a hole on ceiling or wall. Drill a hole of a diameter of 24mm.
Note that this type of installation does not apply to hard surfaces, such as a concrete wall.
24mm
Route the lens unit cable through the ceiling or wall.
5
6
