VIVOTEK
156 - User's Manual
rbgain balance.
“manual” indicates keep current
value.
“rbgain” indicates using rgain
and gbain.
rgain 0~100 50 1/4 Manual set rgain value of gain
control setting.
bgain 0~100 50 1/4 Manual set bgain value of gain
control setting.
exposurelevel CU8131:
0~8
CU8171:
0~12
CU8131: 4
CU8171: 6
1/4 Exposure level
enableblc 0~1 0 1/4 Enable backlight compensation.
(Only used in CU8171)
maxgain 0~100 CU8131: 50
CU8171: 100
1/4 Manual set maximum gain
value.
mingain 0~100 0 1/4 Manual set minimum gain value.
(Only used in CU8171)
color 0, 1 1 1/4 0 => monochrome
1 => color
flickerless 0, 1 0 1/4 Turn on(1) or turn off(0) the
flickerless mode
flip <boolean> 0 1/4 Flip the image.
ptzstatus <integer> 0 1/7 A 32-bit integer, each bit can be
set separately as follows:
Bit 0 => Support camera
control function; 0(not
support), 1(support)
Bit 1 => Built-in or external
camera; 0 (external), 1(built-in)
Bit 2 => Support pan
operation; 0(not support),
1(support)
Bit 3 => Support tilt operation;
0(not support), 1(support)
Bit 4 => Support zoom
operation; 0(not support),
1(support)
Bit 5 => Support focus
