VIVOTEK
20 - User's Manual
General Connection (without PoE)
1. If you have external DI devices, make the connection from general I/O terminal block.
2. Ethernet, power and IO cables are user-supplied.
3. (Optional) Connect DC power cord to a DC Adapter, and then to a power outlet.
1
2
3
