VIVOTEK
User's Manual - 7
Status LED
(LAN port)
Item LED status Description
1
Steady Orange Powered on, and system booting
Orange LED off Power is off.
2
Steady Orange & Green blinking every 1 sec.
(Green LED on for 1 sec., and off for another 1
sec.)
Network is working (heartbeat)
Steady Orange & Green LED off Network failed.
3
Orange blinks every 0.15 sec. + Green blinks every
1 sec. (Orange on for 0.15 sec. and off for 0.15
sec. ) (Green on for 1 sec and off for 1 sec.)
Upgrading firmware
4
Orange blinks every 0.15 sec. + Green blinks every
0.15 sec. (LEDs on together on for 0.15 sec and off
for 0.15 sec., and repeat the pattern)
Restoring defaults
Hardware Reset
The reset button is used to reset the system or restore the factory default settings.
Sometimes resetting the system can return the video server to normal operation. If the
system problems remain after reset, restore the factory settings and install again.
Reset: Press and release the recessed reset button using a straightened paper clip. Wait
for the video server to reboot.
