4
VS8801
VS8401
2
Physical Description
RCA Audio Input
SD/SDHC Card Slot
USB Socket
Status LEDs
General I/O
Terminal Block
BNC Video Input
Recessed Reset Button
Click this button before removing the ash drive
Ethernet 10/100/1000
RJ45 Socket
Power Cord
Socket
Click this button before removing the SD/SDHC card
RCA Audio Input
SD/SDHC Card Slot
USB Socket
Status LEDs
General I/O
Terminal Block
BNC Video Input
Recessed Reset Button
Click this button before removing the ash drive
Ethernet 10/100/1000
RJ45 Socket
Power Cord
Socket
Click this button before removing the SD/SDHC card
