4
Completing the First-Time Setup
19
The rst time you turn on the TV, the Setup App will guide you
through the steps needed to get your TV ready for use.
Before you begin the rst-time setup:
Your TV should be installed and the power cord should be
connected to an electrical outlet.
Your devices should be connected.
To complete the rst-time setup:
1. Press the Power button on the
remote. The TV powers on and
the Setup App starts.
2. Use the Arrow buttons on the
remote to highlight Home Use
and press OK.
3. Use the Arrow buttons on
the remote to highlight your
preferred language, and then
press the OK button.
INPUT
EXIT
GUIDE
BACK
1
4
7
WIDE
MENU
OK
VOL
VOL
CH
CH
3
6
9
2
5
8
0
Choose your mode.
Select Store Demo for in-store display.
Select Home Use for in-home use.
Seleccione "Home Use" por Modo de Casa o "Store Demo" por Demostración de Tienda.
Choisissez "Home Use" pour Mode Domicile ou "Store Demo" pour Démonstration de Magasin.
Store Demo Home Use
4. Use the Arrow buttons on the
remote to highlight your TV
source and press OK.
If you have cable TV, select
whether you have a cable box,
or if you connect the TV directly
to a cable from the wall.
5. If the TV Signal channel scan
screen appears, the TV will scan
for channels, which takes several
minutes. Use the arrow buttons
on the remote to highlight Begin
Scan and press OK.
Otherwise, use the Arrow and
OK buttons on the remote to
select the input your TV source
is connected to.
(The number of inputs may vary
depending on your TV.)
6. When you are nished, “Your VIZIO TV is set up” will be
displayed. The rst-time setup is complete.

Table of Contents

Other manuals for Vizio D24h-C1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio D24h-C1 and is the answer not in the manual?

Vizio D24h-C1 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal23.54 \
Display brightness- cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Native refresh rate60 Hz
LED backlighting typeRazor LED
Supported video modes720p
Viewing angle, horizontal176 °
Motion interpolation technology-
Audio decodersDTS Studio Sound
RMS rated power2 W
Number of speakers2
DVI portNo
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of OSD languages3
On Screen Display (OSD) languagesENG, ESP, FRE
Product colorBlack
Panel mounting interface100 x 100 mm
AC input voltage120 V
Power consumption (max)25.8 W
Power consumption (standby)0.5 W
Power consumption (typical)21.6 W
Sustainability certificatesENERGY STAR
Package depth103.1 mm
Package width652 mm
Package height418.1 mm
Package weight4572 g
CertificationUL, CUL, NOM, FCC Class B, HDMI (CEC, ARC), Dolby Digital
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)111.5 mm
Height (with stand)380.5 mm
Weight (with stand)3270 g
Depth (without stand)53.59 mm
Width (without stand)557.8 mm
Height (without stand)361.9 mm
Weight (without stand)3162 g
