Vizio D50f-E1 User Manual

iv
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
(C Section 810-20)
Grounding Conductors
(C Section 810-21)
Ground Clamps
Power Service Grounding lectrode System
(C ART 20, part )
lectric Service quipment
TELEVISION ANTENNA CONNECTION
PROTECTION
If an outside antenna/satellite dish or cable system is to be
connected to the TV, make sure that the antenna or cable system
is electrically grounded to provide some protection against voltage
surges and static charges.
Article 810 of the ational lectrical Code, ASIPSA 0, provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of the grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it
is left unattended or unused for long periods of time, unplug the TV
from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the
screen of the coaxial cable is intended to be connected to earth in
the building installation.

Vizio D50f-E1 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Features	full-array led backlight, vizio internet apps plus
Tuner	digital
Screen Size	49.5 inches, 50 inches
Refresh Rate	120hz
HDR	no
Built-In Speakers	yes
Surround Sound	dts studio sound, dts trusurround, dts truvolume, dolby digital plus
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	2
USB 3.0 Ports	0
Ethernet	yes
RF Antenna	no
Bluetooth	true, 4.1
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
VGA Ports	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	standard
3D	no
Power Consumption	87 kilowatt hours
Depth with Stand	10 inches
Height with Stand	28 inches
Width with Stand	44.4 inches
Net Weight with Stand	27.34 pounds
Depth without Stand	3 inches
Height without Stand	25.6 inches
Net Weight without Stand	26.68 pounds
