Vizio D58u-D3 User Manual

1
REMOTE CONTROL
APP LAUNCHER
Quickly launch the pictured App.
INPUT
Change the currently
displayed input.
NUMBER PAD
Manually enter a channel.
WIDE
Change the display mode.
ARROW
Navigate the on-screen menu.
POWER
Turn TV On or O.
INFO
Display the info window.
MENU
Display the on-screen menu.
GUIDE
Display the info window.
PIC
Opens the Picture Mode menu.
V BUTTON
Open the VIZIO Internet Apps
Plus
®
(V.I.A. Plus) dock.
CHANNEL UP/DOWN
Change the channel.
LAST
Return to the channel last viewed.
DASH
Use with number pad to manually
enter a digital sub-channel.
(For example, 18-4 or 18-5.)
ENTER
Conrm channel or passcode
entered using the Number Pad.
A/V CONTROLS
Control the USB media player and
streaming video playback.
CLOSED CAPTIONS
Turn closed captions On and O.
EXIT
Close the on-screen menu.
VOLUME UP/DOWN
Increase or decrease loudness
of the audio.
OK
Select the highlighted option.
BACK
Go to the previous on-screen menu.
MUTE
Turn the audio o or on.
Replacing the Batteries
1. Remove the battery cover by pressing down on the arrow
markings and sliding out.
2. Insert two batteries into the remote control. Make sure that
the (+) and (-) symbols on the batteries match the (+) and (-)
symbols inside the battery compartment.
3. Replace the battery cover.
12

Vizio D58u-D3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	57.5 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p, 2160p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	5
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, FCC Class B, HDMI 1.4/2.0, Dolby Digital Plus
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.24 W
Power consumption (typical)	82.6 W
Package depth	183.9 mm
Package width	1392 mm
Package height	879.1 mm
Package weight	24660 g

Weight and Dimensions

Depth (with stand)	284.5 mm
Height (with stand)	828 mm
Weight (with stand)	18840 g
Depth (without stand)	71.12 mm
Width (without stand)	1295 mm
Height (without stand)	762 mm
Weight (without stand)	18340 g
