1
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult the
information below to nd the appropriate mount for your TV model:
Be sure the mount you choose is capable of supporting the weight of
the TV. After you have determined that you have the correct mount
for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, at, stable surface. Be sure
the surface is clear of debris that can scratch or damage the TV.
3. Remove the stands by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed
wall mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
D58u-C3
Screw Size: M6
Hole Pattern: 400mm (V) x 400mm (H)
Weight w/o
Stand:
47.40 lbs
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
9

Table of Contents

Other manuals for Vizio D58u-D3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio D58u-D3 and is the answer not in the manual?

Vizio D58u-D3 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal57.5 \
Display brightness- cd/m²
Native aspect ratio16:9
LED backlighting typeFull-Array
Supported video modes1080p, 2160p
Contrast ratio (dynamic)5000000:1
Viewing angle, horizontal176 °
Display refresh rates supported120 Hz
Motion interpolation technology-
Music appsPandora, Spotify
Video appsNetflix, YouTube
Lifestyle appsFacebook, Twitter
Audio decodersDTS Studio Sound
RMS rated power10 W
Number of speakers2
PC in (D-Sub)No
HDMI ports quantity5
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Wi-Fi standardsWi-Fi 5 (802.11ac)
Number of OSD languages3
On Screen Display (OSD) languagesENG, ESP, FRE
Product colorBlack
Panel mounting interface400 x 400 mm
Sustainability certificatesENERGY STAR
CertificationUL, cUL, FCC Class B, HDMI 1.4/2.0, Dolby Digital Plus
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.24 W
Power consumption (typical)82.6 W
Package depth183.9 mm
Package width1392 mm
Package height879.1 mm
Package weight24660 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)284.5 mm
Height (with stand)828 mm
Weight (with stand)18840 g
Depth (without stand)71.12 mm
Width (without stand)1295 mm
Height (without stand)762 mm
Weight (without stand)18340 g
