Controls and Connections
Front Panel
Front Panel
Remote Control Sensor
Remote Control
Sensor:
When using the remote, point it directly at this sensor.
Left Side Panel
Left Side Panel
USB
Composite AV
3.5mm Audio
3.5mm Audio: Connect headphones, powered speakers, or other 3.5mm
audio device.
Composite AV: Connect external device (DVD player, game
console, etc) with a composite AV cable.
USB: Connect USB thumb drive to play photo
slideshow or to update rmware.
Right Side Panel
Right Side Panel
Power
Menu
Channel Up/Down
Volume Up/Down
Input
Ambient Light Sensor
Ambient Light
Sensor:
Activate through the on-screen menu. When activated,
the sensor adjusts the brightness of the TV based on
the light level in the room. (On E220VA, E260VA, and
E261VA, the sensor is on the front of the TV.)
Power: Turn the TV on or off.
Menu: Display on-screen menu.
Channel Up/Down: Change the channel.
Volume Up/Down: Increase or decrease the loudness of the TVs audio.
Input: Change the input device. With each press of the
button, the TV will display a different input source
