Vizio E552VLE User Manual

Table of Contents
1
Installing the TV ................................................ 3
Inspecting the Package Contents .....................................3
Installing the TV ...................................................................3
Installing the TV Stand .....................................................3
Installing the TV on a Wall ................................................ 4
Controls and Connections .............................. 5
Rear Panel ..........................................................................5
Side Panel ........................................................................... 6
Front Panel .......................................................................... 7
Remote Control ..................................................................8
Replacing the Batteries ...................................................9
Connecting A Device .........................................................10
Connecting Your Devices ................................. 10
Connecting A PC ................................................................11
Connecting an audio device ............................................12
Connecting to your network ..............................................13
Connecting to a Wired Network (Best) ...........................13
Connecting to a Wireless Network ..................................13
Completing the First-Time Setup ...................... 14
Using the On-Screen Menu .............................. 15
Navigating the On-Screen Menu .......................................15
Changing the Input Source ...............................................16
Changing the Screen Aspect Ratio ...................................16
Setting Up Closed Captioning ...........................................17
Changing the Appearance of Digital Closed Captions . 17
Activating the Sleep Timer ..................................................18
Setting the Auto Power Off Feature ..................................18
Adjusting the Picture Settings ............................................18
Adjusting the Advanced Picture Settings ........................19
Adjusting the Color Temperature ....................................20
Adjusting the Picture Size and Position ...........................21
Resetting the Picture Settings .........................................21
Adjusting the Audio Settings ..............................................22
Adjusting the Advanced Audio Settings .........................23
Resetting the Audio Settings ............................................ 24
Using the Network Connection Menu ................................ 24
Connecting to a Wireless Network ..................................24
Changing the Advanced Network Settings ....................25
Testing Your Network Connection ....................................25
Changing the TV Settings ...................................................26
Changing the Input Source .............................................26
Setting the Tuner Mode ....................................................27
Scanning for Channels .................................................... 27
Adding New Channels ....................................................27
Skipping Channels...........................................................28
Changing the Audio Language ...................................... 29
Using the Parental Controls .............................................29
Accessing the Parental Controls Menu ........................... 29
Enabling or Disabling Program Ratings ...........................30
Locking and Unlocking Channels ...................................30
Blocking and Unblocking Content by Rating ..................30
Changing the Parental Control Passcode ......................31
Resetting the Content Locks ............................................ 31
Changing the Names of the Inputs ................................31
Changing the On-Screen Menu Language .................... 32
Setting the Time Zone ......................................................32

Vizio E552VLE Specifications

General

Picture-in-Picture	No
Number of OSD languages	3
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	ENG, ESP, FRE
Certification	CSA, CSA-US, FCC Class B, HDMI V1.4 incl. CEC, ARC, Vizio AQ, Vizio PQ
Wi-Fi standards	Wi-Fi 4 (802.11n)
RS-232 ports	0
HDMI ports quantity	4
USB 2.0 ports quantity	2
Digital audio optical out	1
Consumer Electronics Control (CEC)	Anynet+
Sustainability certificates	ENERGY STAR
Product color	Black
Panel mounting interface	400 x 200 mm
Response time	6.5 ms
Display diagonal	55 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	120 Hz
Supported video modes	1080p
Contrast ratio (dynamic)	100000:1
Supported graphics resolutions	1920 x 1080 (HD 1080)
Backlight type	CCFL
Power consumption (standby)	1 W
Power consumption (typical)	102 W
RMS rated power	15 W

Weight and Dimensions

Depth (with stand)	334 mm
Width (with stand)	1400 mm
Height (with stand)	875 mm
Weight (with stand)	34473 g
Depth (without stand)	125 mm
Height (without stand)	827 mm
Weight (without stand)	29937 g
