Vizio E55u-D2 Installation Guide

English - 24
To mount your Display on a wall, you will need a wall
mount. Consult the information on this page to nd
the appropriate mount for your Display.
Be sure the mount you choose is capable of
supporting the weight of the Display. After you have
determined that you have the correct mount for your
Display, you can begin the installation.
Wall-mounting the Display
Installing a Display on a wall requires lifting.
To prevent injury or damage to the Display,
ask someone to help you.
To install your Display on a wall:
1. Disconnect any cables connected to your Display.
2. Place the Display face-down on a clean, at, stable
surface. Be sure the surface is clear of debris that
can scratch or damage the Display.
3. Remove the stands by loosening and removing
the screws.
4. Attach your Display and wall mount to the wall,
carefully following the instructions that came with
your mount. Use only with a UL-listed wall mount
bracket rated for the weight/load of this Display.

Vizio E55u-D2 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	not included
Screen Size	54.64 inches, 55 inches
Refresh Rate	120hz
Motion Enhancement	clear action 240
Surround Sound	dts studio sound
Speakers Output	10 watts
Number Of Speakers	2
USB Ports	2
RF Antenna	yes
Network	built-in wi-fi, ethernet
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
SmartTV	chromecast
3D	no
Depth with Stand	8.23 inches
Height with Stand	30.69 inches
Width with Stand	48.98 inches
Net Weight with Stand	32.19 pounds
Depth without Stand	10.59 inches
Height without Stand	30.69 inches
Net Weight without Stand	31.31 pounds
