Vizio E55u-D2 User Manual

3
43
To access the color calibration settings menu:
1. From the Picture menu, tap Color
Calibration. The Color Calibration
menu is displayed.
• Color Tuner settings allow you to adjust the HSB color and 11 point
white balance, turn color channels o for testing.
• Calibration Tests allow you to turn display SMPTE, Flat, Ramp, and
Uniformity Analyzer test patterns.
Adjusting the Color Calibration Settings
se the color calibration settings to calibrate the image using HSB, oset,
gain, and 11 point white balance. You can also reset the color tuner values and
perform calibration tests.
Current Picture Mode
Current Color Temperature
Adjusting the Color Tuner Settings
To adjust the color tuner:
1. From the Color Calibration
menu, tap Color Tuner. The
Color Tuner menu is displayed.
2. Tap Color Tuner, the Color Tuner
submenu is displayed.
3. Adjust settings with switches by
swiping left to disable and right
to enable. Adjust settings with
sliders by sliding your nger left to
decrease and right to increase.
To adjust the 11 point white balance:
1. From the Color Tuner menu, tap
11 Point White Balance. The
11 Point White Balance menu is
displayed.
2. Tap each setting and adjust
settings with sliders by sliding
your nger left to decrease and
right to increase.

Vizio E55u-D2 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	not included
Screen Size	54.64 inches, 55 inches
Refresh Rate	120hz
Motion Enhancement	clear action 240
Surround Sound	dts studio sound
Speakers Output	10 watts
Number Of Speakers	2
USB Ports	2
RF Antenna	yes
Network	built-in wi-fi, ethernet
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
SmartTV	chromecast
3D	no
Depth with Stand	8.23 inches
Height with Stand	30.69 inches
Width with Stand	48.98 inches
Net Weight with Stand	32.19 pounds
Depth without Stand	10.59 inches
Height without Stand	30.69 inches
Net Weight without Stand	31.31 pounds
