Vizio E65-C3 User Manual

4
To show or hide the SMPTE Test Pattern or Color Bar Test Pattern:
1. Ensure that you are on an input that is displaying active
content.
2. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the SMPTE Test Pattern or Color Bar Test Pattern
menu is displayed.
SMPTE Test Pattern
Off
3. Use the Arrow buttons on the remote to highlight Off. Use the
Left/Right Arrow buttons to highlight On to show the SMPTE
Pattern or Color Bar Test Pattern.
—or—
To hide the SMPTE Test Pattern or Color Bar Test Pattern, use
the Left/Right Arrow buttons to highlight Off.
4. When you are finished, press the EXIT button.
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain
and Color values you wish to adjust. Press the OK button
and use the Left/Right Arrow buttons to adjust the value
When you are finished press the OK button to save the
setting.
3. When you are finished, press the EXIT button.
All changes here are saved to Color Temperature.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
To turn color channels off and on:
1. From the PICTURE menu, use the Arrow buttons to highlight
Color Calibration and press the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to highlight Color Tuner, and then
press the OK button. The Color Tuner menu is displayed.
3. Use the Arrow buttons on the remote to highlight Red,
Green, or Blue.
4. Press the OK button to turn the color channel off or on. An X
appears over a color channel that has been turned off.
5. Use the Arrow buttons to highlight another color channel to
turn off or on. Only two color channels can be turned off at
the same time.
6. When you are finished with the color channels, press the
EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
29

Vizio E65-C3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	64.5 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	240 Hz
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	184.9 mm
Package width	1551 mm
Package height	958.1 mm
Package weight	29900 g
Sustainability certificates	ENERGY STAR
Certification	cUL, FCC Class B, BETS-7 Issue 2, FCC ID, IC, HDMI 1.4b (CEC, ARC), Dolby Digital Plus

Weight and Dimensions

Stand width	1265 mm
Depth (with stand)	300 mm
Width (with stand)	1445 mm
Height (with stand)	903.8 mm
Weight (with stand)	23400 g
Depth (without stand)	74.93 mm
Width (without stand)	1455 mm
Height (without stand)	843.3 mm
Weight (without stand)	23000 g
