Vizio M43-C1 User Manual

1
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult the information below to nd the appropriate mount for your TV model:
Be sure the mount you choose is capable of supporting the weight of the TV. After you have determined that you have the correct mount
for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is clear of debris that can scratch or damage the TV.
3. Remove the stands by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the instructions that came with your mount. Use only with a UL-listed wall
mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
M43-C1 M49-C1 M50-C1 M65-C1 M75-C1
Screw Size: M6 M6 M6 M6 M8
Hole Pattern: 200mm (V) x 200mm (H) 200mm (V) x 200mm (H) 200mm (V) x 200mm (H) 400mm (V) x 400mm (H) 400mm (V) x 400mm (H)
Weight w/o
Stand:
22.05 lbs 30.07 lbs 32.19 lbs 60.72 lbs 102.29 lbs
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
9

Vizio M43-C1 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	digital
Screen Size	42.5 inches, 43 inches
Resolution	4k (2160p)
Refresh Rate	120hz
HDR	no
Number Of Speakers	2
USB Ports	1
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	vizio smartcast
Remote Control	smart
3D	no
Power Consumption	196 kilowatt hours
Depth with Stand	8.27 inches
Height with Stand	23.97 inches
Width with Stand	37.93 inches
Net Weight with Stand	22.71 pounds
Depth without Stand	2.44 inches
Height without Stand	21.82 inches
Net Weight without Stand	22.05 pounds
