WALL-MOUNTING THE TV
First you will need a wall mount. Consult the provided table below to nd the
appropriate mount for your TV.
Be sure the mount you choose is capable of supporting the weight of the TV.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is
clear of debris that can scratch or damage the TV.
3. If attached, remove the stands by loosening and removing the screws.
4. Attach your TV and wall mount to the wall by carefully following the instructions
that came with your mount. Use only with a UL-listed wall mount bracket rated
for the weight/load of your TV.
M437-G0 M507-G1 M558-G1 M658-G1
Screw Size: M4 M6 M6 M6
Hole Depth: 8 mm 14 mm 14 mm 14 mm
Hole Pattern: 200 mm x 200 mm 200 mm x 200 mm 300 mm x 200 mm 400 mm x 200 mm
Weight w/o Stand: 16.9 lb (7.7 kg) 28.22lb (12.8 kg) 35.94 lb (16.3 kg) 53.35 lb (24.2 kg)
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
Installing a TV on a wall requires lifting. To prevent injury or damage
to the TV, ask someone to help you.
WARNING: Do not use the screws that are included inside the wall
mount holes to mount TV.

Vizio Quantum M558-G1 Specifications

General

Screen Type	led
Wall Mount	300mm x 200mm
Features	quantum color, 90 local dimming zones, smartcast, apple airplay, chromecast built-in, works with siri, google assistant, alexa
Tuner	digital
Screen Size	54.5 inches, 55 inches
Screen Technology	quantum led
Resolution	4k (2160p)
Refresh Rate	60hz
Closed Captioning	yes
Motion Enhancement	clear action 360
HDR	yes
HDR Format	dolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	yes
Surround Sound	dolby digital plus
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	1
Ethernet	yes
RF Antenna	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	smartcast
Smart Applications	amazon alexa, google assistant, siri
Voice Assistant	no
Remote Control	standard
3D	no
Power Consumption	297 kilowatt hours
Depth with Stand	10 inches
Height with Stand	30.6 inches
Width with Stand	48.6 inches
Net Weight with Stand	36.4 pounds
Depth without Stand	2.9 inches
Height without Stand	28.3 inches
Net Weight without Stand	35.9 pounds
